PDC Laser Engraving Machine

Diğer Videolar
December 30, 2022
Kategori Bağlantısı: Fiber Lazer Oyma Makinesi
sohbet Bizimle iletişim kur
Etiketler:
#PCD fiber lazer Oyma Makinesi #metal için PCBN fiber lazer oyma makinesi #PCBN Fiber Lazer Oyma Makinesi
Kısa: Discover the CE Certificate PDC Laser Engraving Machine, designed for precision engraving on PDC diamond surfaces of petroleum drill heads. Featuring advanced CCD visual positioning and 3D graphics capability, this machine ensures high efficiency and accuracy with a competitive price.
İlgili Ürün Özellikleri:
  • Fiber laser source with a wavelength of 1064nm and output power ≤1000W for precise engraving.
  • CCD visual positioning and automatic focusing for accurate 3D graphics processing.
  • Closed-loop high precision work table control system ensures positioning accuracy ≤0.01mm.
  • Standard 3D software input allows combined parameter adjustment for rough and finish machining.
  • Multiple work pieces loading capability, handling up to 64 pcs per cycle for unattended operation.
  • High processing efficiency with a removal rate of 0.005mm per layer and maximum machining depth of 30mm.
  • Air cooling system and no consumables required for low maintenance operation.
  • Industrial camera imported from Germany for superior visual recognition and automatic positioning.
SSS:
  • What is the primary application of the ZT-JGDK200 PDC Laser Engraving Machine?
    It is mainly used for special-shaped diamond surface processing of PDC on petroleum drill heads, capable of engraving complex 3D graphics.
  • How does the machine ensure high precision in engraving?
    The machine features CCD visual positioning, automatic focusing, and a closed-loop high precision work table control system, ensuring positioning accuracy ≤0.01mm and machining precision ≤0.05mm.
  • What are the advantages of the machine's processing efficiency?
    The machine offers high processing efficiency with a removal rate of 0.005mm per layer, maximum machining depth of 30mm, and surface roughness ≤1.2um, making it ideal for industrial applications.
